Part No 90NX00W1-M00430
Model Name P5430UF-TR561D
EAN Code 4712900467840
UPC Code 889349467848
LCD Cover Color & Decoration Dark Grey
Top Case Color & Decoration Dark Grey
On board processor Intel® Core™ i5-6200U Processor, 2.3GHz (3M Cache,
up to 2.8GHz)
Operating System Free DOS
Office N/A
Chipset N/A
Memory Slot 1x
On board memory DDR4 4GB
Memory Max. 12G
DIMM Memory DRAM DDR4 4G
Total System Memory DDR4 4GB + DRAM DDR4 4G
Storage "SATA 500G 7200RPM 2.5' HDD
SATA3 128G M.2 SSD"
EMMC/ISSD N/A
Display 14.0'//LED Back-lit//200nits//HD 1366x768 16:9//AG
External video display modes VGA max. 2048*1536 @85Hz refresh rate
Discrete/Share Discrete
Video Graphics NVIDIA® GeForce® 930MX (N16S-GMR)
IGPU Intel® HD graphics 520
Video memory DDR3L 2GB
Video Camera HD web camera
FingerPrint YES
Wireless 802.11ac+Bluetooth 4.1 (Dual band) 1*1
3G/4G N/A
LAN 10/100/1000 Mbps
Card Reader Spec: SDXC
USB Port "1x USB 2.0
3x USB 3.0"
Interface "1x Headphone-out & Audio-in Combo Jack
1x RJ45 LAN Jack for LAN insert
1x VGA Port (D-Sub)
1x mini Display Port"
Audio "Built-in speaker
Built-in microphone"
Weight (Kg) "1.51 KG (Without Battery)
 1.76 KG (with 3 cell battery)"
Dimension (cm) 33.9(W) x 23.4(D) x 1.97 ~ 2.04 (H) cm
AC Adapter "65W AC Adapter
 Output : 19V DC, 3.42A, 65W
 Input : 100~240V AC, 50/60Hz universal"
Battery 48WHrs, 3S1P, 3-cell Li-ion  Polymer Battery Pack
Keyboard type Chiclet Keyboard
Security N/A
Supplied Accessories Without carry bag
